KSD-007
Keystar
As one factory of leader manufacturer of foldable water bladders and fuel tanks in China. RAINBOW help you find a solution for the permanent or temporary storage of raw water.we custom and wholesale water bladders to help you knowledge the benefits of them.Drinking water is the most abundant nutrient in the body and a critical nutrient for all classes of beef cattle. Storage water and supply the nutrient to livestock so that we can help them growth healthfully.
*Product name:foldable pillow water bladder water storage bag 20000L for livestock drinking
*Model No.:KSD-007
*Material: high resistance PVC tarpaulin
*Coating:double-sided PVC
*Temperature resistance: -30°C to + 70°C
*Dimensions: 20000liter,5.40x5.20m
*Assembly:high-frequency welding or hot air welding
| Capacity | Tank Layflat Size | Tank Approx.Size Filled | Ground sheet Size |
| 1,000L/264 Gal. | 2.60 x 1.50m | 2.10 x 1.00 x 0.50m | 3.10 x 2.00m |
| 2,000L/528 Gal. | 2.60 x 2.30m | 2.00 x 1.70 x 0.60m | 3.10 x 2.80m |
| 3,000lL/793 Gal. | 3.10 x 2.60m | 2.50 x 2.00 x 0.60m | 3.60 x 3.10m |
| 5,000L/1321 Gal. | 4.50 x 2.60m | 3.80 x 1.90 x 0.70m | 5.00 x 3.10m |
| 10,000 L/2642 Gal. | 5.20 x 3.40m | 4.20 x 2.40 x 1.00m | 5.70 x 3.90m |
| 15,000 L/3963 Gal. | 5.20 x 4.50m | 4.10 x 3.40 x 1.10m | 5.70 x 5.00m |
| 20,000 L/5283 Gal. | 5.40 x 5.20m | 4.20 x 4.00 x 1.20m | 5.90 x 5.70m |
| 30,000 L/7925 Gal. | 7.20 x 5.20m | 5.90 x 3.90 x 1.30m | 7.70 x 5.70m |
| 50,000 L/13209 Gal. | 8.30 x 6.50m | 6.80 x 5.00 x 1.50m | 8.80 x 7.00m |
Need a livestock water storage bag 20000L ? Send e-mail or Call at +86-29-8836-9398 to find out more about our flexible water storage solutions!
As one factory of leader manufacturer of foldable water bladders and fuel tanks in China. RAINBOW help you find a solution for the permanent or temporary storage of raw water.we custom and wholesale water bladders to help you knowledge the benefits of them.Drinking water is the most abundant nutrient in the body and a critical nutrient for all classes of beef cattle. Storage water and supply the nutrient to livestock so that we can help them growth healthfully.
*Product name:foldable pillow water bladder water storage bag 20000L for livestock drinking
*Model No.:KSD-007
*Material: high resistance PVC tarpaulin
*Coating:double-sided PVC
*Temperature resistance: -30°C to + 70°C
*Dimensions: 20000liter,5.40x5.20m
*Assembly:high-frequency welding or hot air welding
| Capacity | Tank Layflat Size | Tank Approx.Size Filled | Ground sheet Size |
| 1,000L/264 Gal. | 2.60 x 1.50m | 2.10 x 1.00 x 0.50m | 3.10 x 2.00m |
| 2,000L/528 Gal. | 2.60 x 2.30m | 2.00 x 1.70 x 0.60m | 3.10 x 2.80m |
| 3,000lL/793 Gal. | 3.10 x 2.60m | 2.50 x 2.00 x 0.60m | 3.60 x 3.10m |
| 5,000L/1321 Gal. | 4.50 x 2.60m | 3.80 x 1.90 x 0.70m | 5.00 x 3.10m |
| 10,000 L/2642 Gal. | 5.20 x 3.40m | 4.20 x 2.40 x 1.00m | 5.70 x 3.90m |
| 15,000 L/3963 Gal. | 5.20 x 4.50m | 4.10 x 3.40 x 1.10m | 5.70 x 5.00m |
| 20,000 L/5283 Gal. | 5.40 x 5.20m | 4.20 x 4.00 x 1.20m | 5.90 x 5.70m |
| 30,000 L/7925 Gal. | 7.20 x 5.20m | 5.90 x 3.90 x 1.30m | 7.70 x 5.70m |
| 50,000 L/13209 Gal. | 8.30 x 6.50m | 6.80 x 5.00 x 1.50m | 8.80 x 7.00m |
Need a livestock water storage bag 20000L ? Send e-mail or Call at +86-29-8836-9398 to find out more about our flexible water storage solutions!
