Flexible pillow fuel storage bladders are installed quickly and easily and assume the shape of the space in which they are placed. They can be assembled in places normally difficult to reach, and store diesel,gasoline,jet fuel,transformer oil,and lubricant oil,and so on.Most bigger fuel tank with capacities are used on ground,some smaller one are used on boat which are easily resistant to pressures developed if the vessel is pitching and rolling.
Capacity | Lay-flat size （Length x Width） | Filled height | Net Weight |
M3 | M | M | kgs |
2 | 2.8x2.2 | 0.5 | 25 |
3 | 3.2x2.5 | 0.55 | 35 |
5 | 3.8x3.2 | 0.6 | 45 |
10 | 4.4x4.4 | 0.8 | 70 |
15 | 5.4x4.4 | 1 | 90 |
20 | 6.5x4.4 | 1.1 | 110 |
25 | 7.0x4.7 | 1.1 | 125 |
50 | 8.5x7.0 | 1.1 | 220 |
76 | 11.6x7.0 | 1.2 | 330 |
100 | 11.0x9.5 | 1.2 | 390 |
200 | 16.6x9.5 | 1.6 | 630 |
1.Durable calendared material impervious to diesel
2.Moulded-in loops hold fuel intake/out take in position.
3.Doubled and reinforced seams prevent leakage
4.Captive camlock coulping tight-threaded caps
5.Extra-strength handle for secure tie-down
1.Light in weight,assemble easily.
2.Minimum packing size,transportation and storage handily.
3.No contamination for fuel,which may guarantee the quality of the fuel.
4.High strength of the coated fabric, the adhesion up to 80lb/in.
RAINBOW offer mobile and cost-effective solution for flexible pillow fuel bladder 1 to 200m3 container fuel bags external diesel fuel tank
Flexible pillow fuel storage bladders are installed quickly and easily and assume the shape of the space in which they are placed. They can be assembled in places normally difficult to reach, and store diesel,gasoline,jet fuel,transformer oil,and lubricant oil,and so on.Most bigger fuel tank with capacities are used on ground,some smaller one are used on boat which are easily resistant to pressures developed if the vessel is pitching and rolling.
Capacity | Lay-flat size （Length x Width） | Filled height | Net Weight |
M3 | M | M | kgs |
2 | 2.8x2.2 | 0.5 | 25 |
3 | 3.2x2.5 | 0.55 | 35 |
5 | 3.8x3.2 | 0.6 | 45 |
10 | 4.4x4.4 | 0.8 | 70 |
15 | 5.4x4.4 | 1 | 90 |
20 | 6.5x4.4 | 1.1 | 110 |
25 | 7.0x4.7 | 1.1 | 125 |
50 | 8.5x7.0 | 1.1 | 220 |
76 | 11.6x7.0 | 1.2 | 330 |
100 | 11.0x9.5 | 1.2 | 390 |
200 | 16.6x9.5 | 1.6 | 630 |
1.Durable calendared material impervious to diesel
2.Moulded-in loops hold fuel intake/out take in position.
3.Doubled and reinforced seams prevent leakage
4.Captive camlock coulping tight-threaded caps
5.Extra-strength handle for secure tie-down
1.Light in weight,assemble easily.
2.Minimum packing size,transportation and storage handily.
3.No contamination for fuel,which may guarantee the quality of the fuel.
4.High strength of the coated fabric, the adhesion up to 80lb/in.
RAINBOW offer mobile and cost-effective solution for flexible pillow fuel bladder 1 to 200m3 container fuel bags external diesel fuel tank
